An illustration from Cyclopedia of mechanical engineering; a general reference work. Editor-in-chief Howard Monroe Raymond. Assisted by a corps of mechanical engineers, technical experts, and designers of the highest professional standing, 1908, leaf 105
Fiff. 107. Fig. 108. Still anotlier method of holding work is that shown in Fig.109. The piece is clamped to the face plate. When this is donethere should be a bearing oia the face plate immediately beneaththe clamping strap. Vov example consider Fig. 110. Suppose adisk liaving four feet on one… … The clamps shoidd be placed directly over the feet as in B. Iftliey are placed between the feet at EE the work will be sprungout of sliai)e as shown by the dotted lines in A. Then, when thetool has done its work the shape of the piece, while bolted to the :\IA(HINK SHOP WORK. fiifc plate, will l.e…
