Cyclopedia of mechanical engineering; a general reference work. Editor-in-chief Howard Monroe Raymond. Assisted by a corps of mechanical engineers, technical experts, and designers of the highest professional standing (1908)

American School (Chicago, Ill.), Raymond, Howard Monroe · Chicago American Technical Society · leaf 171

An illustration from Cyclopedia of mechanical engineering; a general reference work. Editor-in-chief Howard Monroe Raymond. Assisted by a corps of mechanical engineers, technical experts, and designers of the highest professional standing, 1908, leaf 171
UNIVERSAL MILLING MACHINE.Brown and Sharpe Mfg. Co. * MACHINE SHOP WORK. 127 THE SHAPER. For light -work tLe sliaper or shaping planer, Fig. 180, is ex-tensively used. It possesses the advantage of rapidity of action.In this machine, as in the plate planer, the tool moves while the

Mechanical engineering

Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
