DRAW STROKE SLOTTER.Baker Brothers. 132 MACHINE SHOP WORK. is shown in Fig. 185. The shape of this tool is such tliat it, isvery strong in the (lirectioii of the thrust, Ijesides liaving a keencutting edge. … H a MACHINE SHOP WORK. PART III. THE MILLINQ MACHINE. The operation knowu as milling differs so Iadically from theremoval of metal by methods previously described, that it meritsiinifh more careful and lengthy disciission than has been devotedto the other nietTiods. Due, also, to its increasing…
