Fig. 159. 354 FORGING 87 A round iron with tiie ends screwed into the cast-iron l)locks and iicidfirnilvby the lock nuts shown. This makes a cheaj) arrangement fora variety of work, as the same luindles may be used on various sets of … 3ec!ion X X Fig. IfiO. blocks. \Miere a great number of pieces are to be made, these l)locksor bending dies may be made of such a shape that they can ije keyedon the steam hammer in place of the regular flat dies. Die Forging. Pieces are sometimes shaped between fornied steeldies where many are to…
