eiglitli of an inclt wider than the stock from wiiich it isforged. The cape chisel is used for cutting key ways, channels,etc., and also for breaking up surfaces too wide to chip witli theflat chisel alone. Cluiunels are dnven across such a surface,leaving raised portions or lands to be removed by… … Fi-;. 43. *slot. As tliis weakens the chisel, it is made comparatively thickin the plane at right angles to the cutting edge. The diamond point chisel is made by drawing out the endof the stock to about -{^ inch square, and grinding the end at anangle with the axis of the chisel, leaving a…
