Cyclopedia of mechanical engineering; a general reference work. Editor-in-chief Howard Monroe Raymond. Assisted by a corps of mechanical engineers, technical experts, and designers of the highest professional standing (1908)
American School (Chicago, Ill.), Raymond, Howard Monroe · Chicago American Technical Society · leaf 89
The tools used on brass and composition cut by ^ scrapingaction and are almost always held at or below the center. Thethree took shown in Fig. 84 called the planisher, graver, andround nose, are typical of all the tools necessary for turning brass. … <n a MACHINE SHOP WORK. 61 cU.^ Tlio manner of lii.-liling these tools in conaoction with tlieT-resfc is illustrated hy the planisher in Fig. 85. Fig. 86 showsHuother view of the T-iest. Typical hand tools for cutting ironand steel are the diamond point or graver and the round nose,
