Cyclopedia of mechanical engineering; a general reference work. Editor-in-chief Howard Monroe Raymond. Assisted by a corps of mechanical engineers, technical experts, and designers of the highest professional standing (1908)
American School (Chicago, Ill.), Raymond, Howard Monroe · Chicago American Technical Society · leaf 153
Fig. 210. men type. At e Fig. 210, we have a cross-section through thesteam chest and exhaust port at A B; and at F, a cross section atG D through the steam port. 127 116 PATTERN MAKING When the cylinder is small (ten inehes or inider in diameter)the pattern is usually built up solid, but if more…
Mechanical engineering -- Dictionaries
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
