fromwhich it will be seen that almost the entire work, with the exception 131 120 PATTERN MAKING of fitting, placing the dowel pins, and forming the two hexagonalends, is done in the lathe. The construction is shown in thesectional illustration of the half-pattern. Fig. 221. The wood forthe two…
