Cyclopedia of mechanical engineering; a general reference work. Editor-in-chief Howard Monroe Raymond. Assisted by a corps of mechanical engineers, technical experts, and designers of the highest professional standing (1908)

American School (Chicago, Ill.), Raymond, Howard Monroe · Chicago American Technical Society · leaf 251

An illustration from Cyclopedia of mechanical engineering; a general reference work. Editor-in-chief Howard Monroe Raymond. Assisted by a corps of mechanical engineers, technical experts, and designers of the highest professional standing, 1908, leaf 251
l)e a hole in the drag plate op-posite the exhaust core to allow for venting and fastening its end. One half of Fig. 00 shows the end view of the flask. The otherhalf shows a section through the middle of the completed mold. HereA is the hollow cylinder core, B is the chest core, C the live steam… … Fig. 91. Plan on Drug. packing the drag until the pattern is covered. Tuck the facing care-fnllv underneath the flange, setting in rods as in core work, to strength-en the overhanging portions. Make a flat joint, F G, at the level ofthe top of the flange, then carefully fit over the print of the…

Mechanical engineering -- Dictionaries

Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
