Cyclopedia of mechanical engineering; a general reference work. Editor-in-chief Howard Monroe Raymond. Assisted by a corps of mechanical engineers, technical experts, and designers of the highest professional standing (1908)

American School (Chicago, Ill.), Raymond, Howard Monroe · Chicago American Technical Society · leaf 362

An illustration from Cyclopedia of mechanical engineering; a general reference work. Editor-in-chief Howard Monroe Raymond. Assisted by a corps of mechanical engineers, technical experts, and designers of the highest professional standing, 1908, leaf 362
ontact. Let Fig. 10 represent the side view of two right coneswhich are in contact along the line EF, which is an element com-men to both. Then R. P. M. of A F G R. P. M. of B F H (4 That is, their revolutionsare to each other inversely asthe diameters of their bases. Ifthe angles OEF and OEF… … ^5^ If the angle between the axes OE and OE is given and it isdesired to find the relative sizes of the two cones whose revolutionsshall have a given ratio, the angles OEF and OEF could be calcu-lated, but the calculation would be rather difiicult and therefore asolution which is partly graphical…

Mechanical engineering -- Dictionaries

Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
