yout is begun.We now have something about which to build. , In this case the designer would first calculate the size of thepiston rod, and determine the fastening to the piston. He wouldthen draw the rod aiid build a hub around it. He would nextcalculate the width or thickness of piston and size of… … IMECHANrCAL DRAWING. inches apart, parallel to and symmetrical with the center line, arethe next to be drawn. Short vertical lines indicate the locationof the packing rings. As the nominal travel of the piston isto be 12 inches, the location of the piston and rings can beshown on both sides of the…
