•*h = i/TO = 4.05 (say 41)Drawing in this size, and tapering the arm to the rim as inthe case of the pulleys, making the depth of the rim according tothe suggested proportions given in Part II, Gears, giving thecenter leg of the T a thickness of J inch tapering to 1 inch, andheavily filleting the… … Fig. la 244 MAC HIKE DESIGX 47 eter, and there will naturally be six bolts, one between each arm. These bolts are in pure shear, and the material of which they are to be made ought to be good for at least 8,0Q0 pounds per square inch fibre stress. The force acting at the circumference of an…
