Cyclopedia of mechanical engineering; a general reference work. Editor-in-chief Howard Monroe Raymond. Assisted by a corps of mechanical engineers, technical experts, and designers of the highest professional standing (1908)
American School (Chicago, Ill.), Raymond, Howard Monroe · Chicago American Technical Society · leaf 310
from which, by a properassumption of the fiberstress S, which should be ^ ^ low, the opening-up tendency of the joint being neglected, the diam-eter at the root of the thread rI^ may be calculated, and the nom-inal bolt diameter chosen. Reference to the table for strengthof bolts, ^iven in the… … MACHINE DESIGN 97 It is very.<.loul)tful if the tension on the flange bolts, due tothe heelingiihont E can be calculated with sutticient accuracy tobe of much value. It is probably better to assume 8 at a low value,say 4,00l), and, in addition, for large and hiirh-speed pulleys, stif-fen the rim…
Mechanical engineering
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
