Cyclopedia of mechanical engineering; a general reference work. Editor-in-chief Howard Monroe Raymond. Assisted by a corps of mechanical engineers, technical experts, and designers of the highest professional standing (1908)

American School (Chicago, Ill.), Raymond, Howard Monroe · Chicago American Technical Society · leaf 385

An illustration from Cyclopedia of mechanical engineering; a general reference work. Editor-in-chief Howard Monroe Raymond. Assisted by a corps of mechanical engineers, technical experts, and designers of the highest professional standing, 1908, leaf 385
tions. The di-mensions may then be testedby the above equations, thatthe safe working stresses maynot be exceeded, the dimen-sions being then modified ac-cordingly. The steel of which bothcotter and rod would ordina-rily be made has range ofworking fiber stress asfollows : Tension, 8,fKJ0 to 12,000… … Fig. 73. 874 MACHINE DESIGN 1G9 the eiul. and tendency to split. The uncertainty of cast iron toresist these is so great that the hub or socket must be rery clumsyin order to have enough surplus strength. This is always a notice-able feature of the cotter type of fastening, and cannot well…

Mechanical engineering

Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
