Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)
American School (Lansing, Ill.) · Chicago : American school of correspondence · leaf 279
the shaft, Y^. The weight of the cone hangs upon the cone belt, D^,and keeps it tight. The connection, from the bottom cone to the gearing, is throughthe cone gear, C^, which has twenty-two teeth. This gear is some-times changed when the diameter of the empty bobbin is so small thatthe difference… … ^ < bsi < K OS fa ^ 3 rt 5 w COTTON SPINNING 209 the bobbins to run at a greater speed. The cone belt is then shiftedalong the cones until the position of the belt is sftch that the rovingtakes up or winds correctly. The taper gear, F^, has from eleven to fourteen teeth. This is adriven gear…
Textile fabrics · Textile industry
