Cyclopedia of textile work; a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)

American School of Correspondence · Chicago, American School of Correspondence · leaf 188

An illustration from Cyclopedia of textile work; a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1911, leaf 188
learer,D1. In addition to theirown weight, the top cal-ender rolls are leverweighted, the rod, Ei,connects the 3-oke whichis over the bearings ofthe top Iolis with theweight lever, N^, uponwhich is the weight, P. The fulcrum for the weight lever is a projecting lug. Si, upon the frame of the… … Fig. 109. Diagram of Gearing ofSliver Lap Macliine.

Textile fabrics · Textile industry
