idual head. Theshaft, F, is in,motion all of the time that the main line is running. COTTON SPINNING 167 motion being transmitted to the tight and loose pulleys of eachhead by the belts, E. By this means the stopping of one head ina piocess does not affect the others. Sometimes the drawing frames… … Fig. 138. . Diagram of Railway Head Dralt Gearing. esses. The cans from F and IT deliver in the same alley while thosefrom G deliver at the back of IT When one head is used in a process, it is referred to as a frameand the underneath shaft is generally omitted, the frame beingdriven directly from…
