Cyclopedia of textile work; a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)

American School of Correspondence · Chicago, American School of Correspondence · leaf 230

An illustration from Cyclopedia of textile work; a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1911, leaf 230
necessary movements shall be made by the tenders of the drawingframe. Operation. The actual operation of drawing is very simpleand consists of passing the slivers between several pairs of rolls,each pair running at a greater speed than the preceding one. Therolls are set at a certain distance… … axoxn Fig. 139. Plan of Card Room Showing Dra\ving Frames. to Fig. 143, which shows in section four pairs of drawing framerolls. The cotton enters between the back rolls, DD, and is drawnbetween the next pair, CC. JSTow as the speed of CC is slightlymore than that of DD, it is evident that the…
