Cyclopedia of textile work; a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)

American School of Correspondence · Chicago, American School of Correspondence · leaf 231

An illustration from Cyclopedia of textile work; a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1911, leaf 231
Fig. UO. Elevation Showing Drawing Frames. tween the fluted carrier roll, P, and the top roll,. N, then betweenthe four pairs of draft rolls, D,C,B,A, where it receives a draft,usually as great as the number of cans put up at the back. Thus, … Plan of Card Room Showing the Drawing FramesArranged Longitudinallj. if there are six cans at the back, and the sliver from these cans isdrawn through as one sliver, or doubled six into one, the machineis given a draft of six, so that the weight of the sliver being de-livered is the same as the…

Textile fabrics · Textile industry

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
