er screw,D, with right and left threads, builder rack, I^, and top and bottomjaws, V, and, X-. A gear P, which is upon the lifting shaft, A^ is incontact with the builder rack. The rotations of the lifting shaft causethe builder to slide up and down on the guide rod, W^. On the stem of the builder… … 13 ^ -W- 1 ir 24S 202 COTTON SPINNING screw from the cone rack, P, by the taper gear. At each end of thetraverse, the builder screw is turned a trifle and the jaws are broughtmore closely together. The builder and parts directly connected areshown on an enlarged scale in Fig. 170. VSTien the bobbin…
