it is enlarged slight-ly, so that the cotton may be thrown in readily. The pipe maybe inverted and the cotton drawn up instead of down which is much better, as it affords an op-portunity for pieces of hoop iron,nails etc., to drop out, whilewith the pipe leading down, asin the drawing, the heavy… … Fig. 27. for the feed end of the pipe, which embodies the points of bothpipes previously referred to in Fig. 26. The shape of the pipepermits the cotton to be dropped in and the vertical part allows 38 COTTON SPINNING. the heavy dirt to fall to the bottom, where it can be removed. It is considered…
