Cyclopedia of textile work : a general reference library on cotton, woollen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1907)

Chicago : American school of correspondence · leaf 287

An illustration from Cyclopedia of textile work : a general reference library on cotton, woollen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1907, leaf 287
)ol)bin, and E the empty bobbin. The yarn is represented as passingthrough the traveler by the line Y. Withthe full bobbin (Diagram B) the pull ofthe yarn is nearly parallel with the ringand the traveler is rotated with com-parative ease, but with the empty bob-bin (Dagram A) the pull of the yarn… … Fig. 147. Plan of Clamp foi- Fastening Ringin Ring Kail.

Textile industry · Textile fabrics
