dog S to drop backinto place in the slide S^, so that a roll on gear S^, which is drivenfrom the gear S^ on the drawing-in shaft, may force the drawing-outslide and latch rod back into place. This allows the latch rod tocatch on the casting S^-, holding both the slide and rod in position. The… … 5 o < -a o w o a. WOOLEN AND WORSTED SPINNING 261 to be drawn in. The drawing-in clutch is thrown out of gear by thecarriage striking against the lever Y (Fig. 161), which releases thebacking-off lever S*^, allowing the spring S to draw it to a neutralposition. During the running in of the…
