Cyclopedia of textile work : a general reference library on cotton, woollen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1907)

Chicago : American school of correspondence · leaf 214

An illustration from Cyclopedia of textile work : a general reference library on cotton, woollen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1907, leaf 214
fted the pawl, O^, out of the notch in the notched wheel,marked by the numeral, II. Fig. 128 shows the cams as having made about one-half ofa revolution. This movement has advanced the cam roll from Ato B and has caused the pawl to move from above notch II to IIIwhile the gradually decreasing…

Textile industry · Textile fabrics

Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
