, one end of which is attached to the quad-rant arm, Q, the other fastened to the winding drum, W^ as shown inFig. 223. Connected to this drum is a gear of sixty-eight teeth, which / zy QC^ a* -/—/——M6 sA. … // CLf —-f- -7^^, O^^ < I1 Ul )V) drives a gear of thirty-four teeth, the latter connected to the drumshaft by a pawl and ratchet; the spindle drum makes two revolutionsto one of the winding drum. 325 284 COTTON SPINNING While drawing and twisting are going on, the winding drum isdriven by a…
