Cyclopedia of textile work : a general reference library on cotton, woollen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1907)

Chicago : American school of correspondence · leaf 371

An illustration from Cyclopedia of textile work : a general reference library on cotton, woollen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1907, leaf 371
nt roll is driven from thetwist gear, as already described, but when it runs in, motion is com-municated to the front roll, from the carriage shaft, through the gearsof twenty-two, fifty and seventy teeth (Fig. 222) by the pawl engagingthe teeth of the roller motion gear. 329 288 COTTON SPINNING…

Textile industry · Textile fabrics

Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
