Fig. G2. half of the warp can be alternately raised for the passage of theshuttle. The warp is kept in tension by means of weights connected … Fig. 63. to a rope passing once or twice round the warp beam. The clothbeam is provided with a ratchet wheel and pawl M, also with ahandle Z, for winding on the cloth as it is woven. In Fig. 64 only one each of the leeses is shown, but as 51 w TEXTILE DESIGN. .there must be one to each pair of warp…
