Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)

American School (Lansing, Ill.) · Chicago : American school of correspondence · leaf 110

An illustration from Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1911, leaf 110
es inthe least it binds the shaft. This partconstructed in the following manner isrepaired in much less time: (see Figs. 50and 51). If the lower portion of the laysword is bolted to a bracket, which is set-screwed to the rocker shaft, it is a com-paratively easy matter to loosen the bracket from… … Fig. 49. Lay Sword witliKocker Shaft Connections. 91 84 WEAVING. or nose. A circular plate is compounded with the boss, and throughwhich the shaft passes, this portion being fixed to the shaft. At-tached to this fixed portion should be the outer portion of the cam,which comes in contact with the…
