Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)
American School (Lansing, Ill.) · Chicago : American school of correspondence · leaf 117
is shows where the skill in fixins; is re-quired; the setting of the pick motion must be in perfect timewith the shed, so that the shuttle will not rub unduly against theselvedge threads. Fig. 56 shows a cam with a dwell of ^ the revolution of thecrank chaft. Under ordinary circumstances this is… … WEAVING- 89 pick motion there will be poor selvedges, the threads breaking fre-quently; also more power is required to drive the shuttle across thelay, for on coarse cloths a large shuttle is necessary in order to holda reasonable amount of filling. A very practical cam one-half dwell, is shown at…
Textile fabrics · Textile industry
Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
