Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)

American School (Lansing, Ill.) · Chicago : American school of correspondence · leaf 162

An illustration from Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1911, leaf 162
in placewhen in the box. The part which a particular binder plays in theproduction of a loom, is not taken sufficiently into account, andcareful consideration of the following is consequently necessary.There are two distinct shapes; we will term them the bow orblunted swell, and the gradual tapered… … Fig. 86. Blunt Shaped Binder. access; consequently the shuttle strikes hard against the swell inentering. More power is required to drive the shuttle when thisswell is used, because it comes suddenly in contact with a toogreat resistance. This will in turn cause undue friction on thebinder pin,…
