aller warp requires less weight or tension, but Fig.95, shows a motion designed to control itself. A is the whip rollarm, the lower portion of which is in contact with the frictionlever; the friction lever rests on the pulley C ; on the same shaftas C is a small spur gear, which meshes into the… … WEAVING. 141 is fixed to the lower portion of the loom ; to the end of this arma strip of iron is fixed A inch by i inch, and 18 inches long. Kshows the shape of this strip. The bend of the strip is held incontact with the yarn on the beam by means of the spring L ; thisspring is connected to the…
