Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)
American School (Lansing, Ill.) · Chicago : American school of correspondence · leaf 350
the gear isfixed on the shaft in contact with the rack. An arm is set-screwedon the outer end of the shaft, and to this arm a long lifting rod isattached. The bottom of the rod is placed on a stud attached tothe face of a round iron plate that is set-screwed on the pick camshaft. 3oa JACQUARD… … the griffe at C. The belt motion is a simple arrangement, but thegriffe must act freely and perfectly straight or the griffe will notdescend low enough to allow the hooks to be pressed off by thecylinder. 3Q9 32 JACQUARD MACHINES THE RISE AND FALL OR CLOSE SHED MACHINE The illustration, Fig. 31,…
Textile fabrics · Textile industry
Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
