An illustration from Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1911, leaf 127
lever e and a movable weight j on the lever. To increase thepressure of the guide against the cone, move the weight j toward theouter end of the lever. The softer and finer the yarn, the less pressureis required, and for knitting yarn, the pressure should be reducedto the least quantity. Adjusting… … Fig. 38. Univeisal Differential Tension Mechanism. KNITTING 95 and sufEcient tension placed upon it to keep it in line for uniformdelivery to the cone. On the lever h, which is connected to themovable tension blade d by means of the link i, is a weight k, whichcan be shifted to increase or diminish…
