Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)
American School (Lansing, Ill.) · Chicago : American school of correspondence · leaf 160
Fig. 67. Plain Machine svith Fabric Roll in Place of Can. K. The thread guides L are fixed to the stationary cam dial in amanner to properly present the thread to the needles at points wherethe dial needles are operated by the cams. 138 … KNITTING 125 The bevel gear ring D receives its motion from the spur gear D,which is fixed to the driving shaft D^ (See Fig. 61) and on which aretight and loose pulleys. The shaft D^ is mounted at the inside endin a bearing in the right housing plate, and at the outer end in a bear-ing in the…
Textile fabrics · Textile industry
Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
