Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)

American School (Lansing, Ill.) · Chicago : American school of correspondence · leaf 172

An illustration from Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1911, leaf 172
liams MachineStationary Needle Cylinder. The stitch cam C controls and regulates the length of the stitchfor both sets of needles. In Swiss knitting, the top and the bottomcam draw their yarn separately, which makes a much more elastic 148 KNITTING 133 fabric. The foreign machine manufacturers… … Fig. 74. Projection of Cam Ring. of the stitches. Without this cam, a tight or stiff needle would makea slack line in the fabric. The land or tuck cam B lands the needles to a tuck so that all thelatches are safely opened before the guide covers the needles for pla-
