An illustration from Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1911, leaf 274
m outside the plate has feather-splined on it a gear n^, whichis kept on by the screw n^. The gear meshes into the rach n^, whichis connected to the slide block n*, fitted into the guideway n^ of theplate N. When the rack is moved up it turns the gear on the stem ofthe switch and sets it in… … finished, to lead down all the needles previously lifted, and then to beraised in circular knitting. The rack has a cam face at one side, with which co-operates alocking device n^, which serves to hold the rack in position as left byits actuating device. When the narrowing in the heel and toe…
