An illustration from Cyclopedia of textile work : a general reference library on cotton, woollen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1907, leaf 118
he sixth revolution, and has started upon the seventh beforethe guide has made a complete reciprocation and reached its startingpoint. The effect of this is to cause the yarn to cross over the pre-ceding coils at the end, and form a regular succession of spirals,building up the entire cone. 105 92… … Fig. 3r. Universal Gaiuer Meehanism. rides, or leaving spaces between, forming one compact, uniformpackage from start to finish. The weight q holds the belt imderuniform strain to insure accuracy at all times. The gear pinion wand the gear u are enclosed in a casing and run in oil, thus assuring 106
