Cyclopedia of textile work : a general reference library on cotton, woollen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1907)

Chicago : American school of correspondence · leaf 122

An illustration from Cyclopedia of textile work : a general reference library on cotton, woollen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1907, leaf 122
lever e and a movable weight j on the lever. To increase thepressure of the guide against the cone, move the weight j toward theouter end of the lever. The softer and finer the yarn, the less pressureis required, and for knitting yarn, the pressure should be reducedto the least quantity. Adjusting… … Fig. 38. Universal Differential Tension Mechanism. 108 KNITTING 95 and sufficient tension placed upon it to keep it in line for uniformdelivery to the cone. On the lever h, which is connected to themovable tension blade d by means of the link i, is a weight k, whichcan be shifted to increase or…

Textile industry · Textile fabrics
