Cyclopedia of textile work : a general reference library on cotton, woollen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1907) Chicago : American school of correspondence · leaf 61
oth while being knitted, and is a most important factor inproducing good cloth with a minimum of broken needles, detaildrawing is given in this diagram. The crank connection 32, is attaclied to the upper end of theconnecting rod 31 ; on the other connecting rod 31, is a cylindrical 50 KNITTING. 39… … Fig. 19. Outside Circles. when the crank actuated by bevel gear 11, on shaft 10, lifts thespring connecting rod mechanism. Spring 33, is so arranged be-tween washer 29, fastened to the upper end ©f one of the rods 31,and link washer 28, fastened to the lower end of the other rod, 51 40 KNITTING.… Textile industry · Textile fabrics
Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
