arge pipe B B, runsa smaller pipe E, througli which steam is passed in the direction 72 TEXTILE CHEMISTRY AND DYEING. 03 indicated by the arrow head. This steam pipe heats the liquor inBB, and this together with the fact that a certain amount of steamis continually escaping at the bottom through… … Fig. 31. Liming Macliine. liquor comes against the Baffle plate or bonnet P, it showers overthe surface of the material which is contained in the kier, gradu-ally leaches through it, passes through the false bottom, and isfinally brought to the top again through BB. The great loss of heat from this…
