Data for use in designing culverts and short-span bridges (1913)
Moorefield, Charles H. (Charles Henry), 1883-, United States. Bureau of Public Roads · Washington : U.S. Dept. of Agriculture, Office of Public Roads : G.P.O. · leaf 32
i UP-STREAM END HSLF END YIEW HALF SECTION Typical Design for a T-Beam Bridge. Bui. 45, Office of Public Roads, U. S. Dept. of Agriculture. Plate IX, … Typical Design for an I-Beam Bridge. T-BEAM SUPEBSTBUCTUBES. 21 broken stone or gravel may be readily and cheaply obtained, it isfrequently well to construct the side and end walls of plain concrete.Plate VII shows a design for a box culvert which takes into accountsome of these conditions. T-BEAM…
Culverts Design · Bridges Design and construction
