Anthony, Gardner Chace, 1856- [from old catalog], Ashley, George Francis, [from old catalog] joint author · Boston, D. C. Heath & co. · leaf 118
to the axis ofthe cylinder. 2. Determine its trace in theplane of the bases of the cylinder and cone.3. Through this trace draw lines in theplane of the bases of cylinder and cone cuttingthese bases. These lines will be the traces ofthe auxiliary cutting planes. 4. From thepoints of intersection of… … 102 DESCRIPTIVE GEOMETRY Construction. Fig. 1T4. Through theapex of the cone draw line A parallel to theaxis, or elements, of the cylinder. This linewill be common to all auxiliary cutting planes,and its horizontal trace, b\ will be a pointcommon to all their horizontal traces. JTNisone such trace…
Geometry, Descriptive
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
