on the shaft between two cast-brass end plates, TWO-HORSE-POWER SELF-STARTING INDUCTION MOTOR 145 which also serve to connect the ends of the rotor conductors. There are29 of these, each f in. in diameter and yj ins. long; the holes in the rotordiscs are 13-32 in. in diameter, and may be drilled… … FIG. 177 STATOR WINDINGS After the stator is finished the slots and end surfaces of the core shouldbe insulated by means of red rope paper 0.025 in. (25 mils) thick, whichshould be thoroughly varnished with shellac before being put in place.The main stator winding must not be put on until the…
