Designs for small dynamos and motors (1906)

Poole, Cecil Percy, 1863- · New York : McGraw · leaf 34

An illustration from Designs for small dynamos and motors, 1906, leaf 34 — FIG. 21 ONE-FOURTH HORSE-POWER MOTOR WITH RING ARMATURE 25 The armature core, spider, and shaft are shown, partly in cross-section,by Figs. 23 and 24. The core is built up of low-carbon annealed steeldiscs 5 ins. outside diameter and 2§ ins. inside, not more than 25 milsthick; these are assembled… … FIG. 23
