general distribution ofrooms is indicated roughly without minor de-tails, as doors and windows. Ground Plcin. That one of a set of archi-tectural drawings which shows the ground storyof a buildmg, or, in some cases, of the basementstory. It is usual to consider the ground planas the primarj-… … Planmxg: Church at Kalat SEMAy, Stkia;5th Cextuky. O, colaniQ of S. Simeon ^tylUes. The circle A, A. A. fixesthe Hypaethral octagon. The circle B. R, fixes the exterior ofthe absidioles. The circle D, D. tixes the length of the threegreat porches north, south, and west. The circle H, K. S,fixes the…
