al. They are denoted by HP217 PROJECTION and VP, respectively. Their intersection is astraight line called the ground line, denoted byGL. Plans; Ehcutiuim. The projection u[)onIIP is called the horizontal projection, or ])lan;that upon VP, the vertical projection, or ele-vation. The iilan and… … Projection: BvzAXTiNK Groined Vault shown in IsometricProjection. ( VP). Upon HP let any object, .such as arectangular block, be placed, and let lines bedrawn through all of its points perpendicularto IIP, giving its plan, and other lines perpen-dicular to VP, giving its elevation. If now the paper…
