A dictionary of architecture and building; biographical, historical and descriptive (1901)
Sturgis, Russell, 1836-1909 · New York, Macmillan · leaf 556
combination of groined andcloistered vaulting, occurring in a mosque atEphesus. (/) A square room may be covered by four951 VAULT quadripartite vaults, each springing at one ofits corners from a central pillar, as in Fig.21. In a similar manner, a square space maybe covered by nine vaults on four… … Fig. 50 (Plan and Section). the main vault, but both springing from thesame level, so that the intersection is not com-plete (Figs. 22, 23, 24). The horizontal pro-jection of the groin line is a hyperbola. Welshvaults are unknown in Koman work, but arecommon in Romanesque and the later…
Architecture
Internet Archive · University of Toronto, Robarts Library · Public Domain Mark 1.0. Free to use for anything.
