Fio. 87 (Plan).intersection of nave and transepts. The ridgesenclose a central square which is covered by … Fig. 88 (See Fig. 87). extending the groin and transverse ribs to thecentre. 966 VAULT (&) Figures 6G, 07, show how irregular spacesmay be covered by vaults with eight cells. (c) Covering an octagonal space. Figure 68is a plan, ami G9 a section, of an octagonal vaultwhose internal angles are…
