A dictionary of architecture and building : biographical, historical, and descriptive (1902)
Sturgis, Russell, 1836-1909 · New York : The Macmillan company · leaf 566
ethods of jointing panels are shown inFig. -45. In early e.xam])les only groin and transverseribs are used, and each starts with its full sec-tion, but later on they are bunched together,each starting with only its soffit roll visible, asin Fig. 46. As they rise the section developsuntil the ribs… … Fig. 7-t. Analysis of Rib Vaulting. A. Simple. Fig. 47. From Castle Campbell, Scotland. Fig. 48. The panel vaulting of the AfterGothic in France. B. Compound. It will be best to classifythese according to the number of ceDs.901 VAULT 1. Tripartite. These cover a triangnlarspace, which usually…
