amo-electric machine is shown in Fig. 353. This ma-chine is designed to maintain constant potentialat its terminals. There are two varieties of series and shunt-wound dynamos, viz.: (1.) Long-shunt compound-wound dynamo. (2.) Short-shunt compound-wound dynamo. (See Machine, Dynamo-Electric,… … D D D D Fig. 334. Series Dynamo. connected in series with the armature circuityso that the entire armature current must passthrough the field coils. A series dynamo-electric machine is shown in^l% 354* Here the armature circuit, the fieldcircuit and the external circuit are all connectedin series.…
